A villa garden in Hafr Al-Batin becomes the place the family gathers every evening once it has a pool, as long as the pool, the planters around it and the waterfall behind it are built as one piece rather than as separate add-ons. When Aemar Al-Maryam General Contracting takes on swimming pool construction in Hafr Al-Batin, the job includes the reinforced concrete pool with its waterproofing, tiles and pipework, the stone-clad built planters around it, the wall waterfall that spills onto the water, and stainless steel ladders and handrails. Our entry prices: SAR 12,900 for a compact garden pool, SAR 19,400 for 3×6 m, SAR 29,500 for roughly 4×9 m and SAR 3,700 for a wall waterfall. Treat each as an estimate until inspection and agreement, and reach us by phone or WhatsApp on 0547879578.
We work out of Dammam and drive up to Hafr Al-Batin on planned trips; the cost of those trips is worked out once we have seen the site, based on how many days and stages the job needs. Because the pool, planters and waterfall are built on the same site by the same crew, combining them in one project spreads the cost of those trips over more items and lowers the share each one carries.
The garden pool package, in short
- The pool: reinforced concrete with a skimmer or overflow system, immersion-grade waterproofing, pool tiles and pressure-tested pipework.
- Around it: built planters, waterproofed and clad in stone, and a wall waterfall falling onto the water.
- The tiles: every tile, floor and wall alike, sits on solid adhesive made for submersion, with nothing hollow beneath it.
- The ladders: stainless steel, fixed in anchor sockets cast into the coping and bonded to earth.
- Prices from: SAR 12,900 for the pool, SAR 3,700 for a wall waterfall and SAR 460 for a stainless ladder.
- Machinery: a pool specialist specifies and supplies the pump, filter, sanitiser and lamps, and our crew fits and tests them.
- Next step: send garden photos, rough measurements and the wall you picture the waterfall on to 0547879578 by WhatsApp.
Pool, planters and a waterfall: how we plan a villa garden in Hafr Al-Batin
Planning a villa garden with a pool in Hafr Al-Batin starts from the seating area, not from the pool: where will the family sit, and what will they look at? Very often the answer is a rectangular pool in front of the majlis or the outdoor seating, the boundary wall behind it turned into a waterfall, and built stone planters on either side carrying greenery that softens the hard edges of the yard. The arrangement looks simple, yet every part depends on the others. The waterfall needs a waterproofed wall, a pump and power. The planters need drainage that never runs into the pool. And the pool itself has to keep clear of the foundations under the yard wall and the villa.
■ The pool
A rectangle sized to the garden, with stone or tiled coping and either built steps or a stainless ladder.
■ The wall waterfall
A waterproofed wall clad in stone or tile, from which water slides down onto the pool surface.
■ The planters
Built in block or concrete, waterproofed inside, with their own drainage and stone cladding.
■ The deck
Slip-resistant paving laid to falls that carry water away from the pool and from the villa footings.
We draw all of these together before anything is dug and fix three levels: the water level of the pool, the top of the planters and the outlet of the waterfall on the wall. Then we agree the sequence of work. The shell comes first, then the waterfall wall and planters, then waterproofing, tiling and stone cladding together, so that stone work above never damages finished pool tiles below. Getting the order right saves the most common and most expensive repair we see in garden pools: broken tiles and punctured waterproofing caused by trades working out of sequence.
Pool construction company in Hafr Al-Batin: what we build and what we do not
As a pool construction company in Hafr Al-Batin, we take on everything that is built: excavation, the reinforced concrete shell, waterproofing, tiles, mosaic and coping, the buried pipework, the equipment room, power and earthing, waterfalls and their basins, planters and stainless steel ladders. What moves, heats and lights the water is a different trade: a pool specialist sizes the pump, sand filter, sanitiser, heater or chiller and submerged lamps to the volume of water, and our crew then fits and tests them alongside that specialist. We do not offer pool cleaning or monthly maintenance contracts, and we do not do planting or landscaping. We build the planter and hand it over ready for the gardener.
This split matters when you compare offers. A quote that bundles a named pump and filter at a fixed price before anyone has calculated the water volume and pipe runs is guessing. We prefer to size the room, the pipes and the power for the equipment the supplier will specify, and to price that equipment once it is chosen.
Home pool types and sizes in Hafr Al-Batin
The reinforced concrete pool is what we build in Hafr Al-Batin gardens. It can be cast to any size and shape the garden allows, it carries tiles, glass mosaic and stone coping, and it ties into the waterfall and planters as one structure. These are common sizes with typical depths:
| Approximate size | Typical depth | Suits | Starts from |
|---|---|---|---|
| About 2.5 × 4.5 m | around a metre | A small courtyard for a cool dip | SAR 12,900 |
| 3 by 6 m | sloping 0.75 → 1.4 m | The usual villa garden | SAR 19,400 |
| Roughly 4 by 9 m | sloping 0.9 → 1.8 m | A mid-sized garden with room to swim laps | SAR 29,500 |
| About 5.5 × 10.5 m | sloping 1 → 2 m | A wide garden and a big household | SAR 38,800 |
A block-built pool in Hafr Al-Batin: is it a cheaper alternative?
Some offers describe a pool with walls of concrete block. On its own, a block wall does not resist water pressure from inside and soil pressure from outside the way a designed reinforced concrete wall does, and it has many more joints for water to find. That is why our shells are reinforced concrete cast to the engineer’s drawing, and block is kept for the things around the pool: the planters, the waterfall wall and the equipment room.
Fibreglass or concrete?
Fibreglass pools arrive as one moulded unit from a factory, are craned into the excavation and backfilled. It goes in faster but is limited to the factory sizes and shapes. We do not make or sell fibreglass shells, although we can prepare the excavation, base and surround for one. In a garden where the pool connects to a waterfall and built planters, concrete is the better fit because it is designed together with everything around it.
Garden pool designs in Hafr Al-Batin: which shape suits your yard?
The shape of a garden pool in Hafr Al-Batin is decided by the size of the yard, the position of the seating and the path of the sun before it is decided by taste. The rectangle is the most requested because it uses the width of the garden well, tiles cleanly and takes a ladder easily, and a wall waterfall sits naturally on either its short or long side. An L-shape suits a long, narrow garden, putting a shallow section beside the seating and the deeper arm further away. Curved shapes feel more natural beside stone planters but need more formwork and far more tile cutting, so they cost more.
■ Rectangle facing the seating
The simplest to build; a waterfall on the opposite wall becomes the main view.
■ L-shaped pool
A shallow leg with built steps for children and a deeper arm for swimming, wrapping a corner of the garden.
■ Pool with a built bench
A tiled concrete seat inside the water beside the waterfall, for sitting in the pool.
■ Curved pool between planters
Blends with stone and greenery, with more careful setting-out of tiles and coping.
Whichever shape you choose, we keep a walking strip around the pool, usually at least a metre at its narrowest point, place the shallow end on the side children reach first from the house, and put the equipment room in a corner close to the pool but away from the seating so the pump is not heard. Hafr Al-Batin has hot summers and relatively cold winters, so it helps to shade part of the seating and to leave space in the equipment room for a heater if you want to use the pool in winter.
Building a concrete pool in Hafr Al-Batin, step by step
- 1Drawings and levels
An engineered drawing for the shell, plus fixed levels for the coping, planters and waterfall outlet. - 2Excavation
Machine digging with working space for formwork, hand trimming of the floor and a check of the soil. - 3Blinding and rebar
A thin lean-concrete base, then the floor and wall bars raised on spacers so the cover stays correct. - 4Pipework and sockets
Main drains, return inlets, skimmer bodies and ladder sockets fixed before the pour. - 5Casting the shell
Sulphate- and salt-resistant mix, waterstop strips in every joint, and a week or more of keeping it wet. - 6Fill test
The bare shell is filled for three days to saturate, then the loss is measured over 72 hours. - 7Waterproofing and tiles
Immersion-grade waterproofing, tiles in a full adhesive bed, then grout and coping. - 8Ladders and equipment
Stainless ladders fixed, equipment installed with the supplier and the pool filled gradually.
The soil and water under your garden in Hafr Al-Batin
Being inland, Hafr Al-Batin should not be treated like the seaside towns of the Eastern Province where water sits close below the surface, but nor should anyone promise dry ground without looking. We check the soil at the inspection and again during excavation: how firm it is, how damp it is and whether there is old fill or building rubble under the garden. If water appears or the soil is weak, we pump it out or replace the soft layer with compacted material before the blinding is cast, and those items are priced at inspection. Where an old patio or slab must be broken up before we dig, our demolition contractor in Hafr Al-Batin page explains the approach.
How long does a garden pool take?
A medium pool usually takes four to eight weeks, and the waterfall and planters add days for building and cladding. The time that cannot be shortened is curing, the fill test, and the roughly three weeks the tiles need before the pool is filled. For pouring and curing concrete in the heat, see concrete pouring in Hafr Al-Batin.
Pool waterproofing in Hafr Al-Batin
Pool waterproofing in Hafr Al-Batin comes after a successful fill test and once the surface has dried. Our standard system, a flexible cement-based membrane that can stay under water for good, is priced from SAR 74 per square metre; it goes on in two passes, with mesh or tape reinforcing each corner and every pipe opening. Alternatives are a PVC liner from SAR 92 per square metre or an epoxy finish for pools from SAR 138. Where the soil around the pool is damp, we add a bituminous coat to the outside of the walls before backfilling. It is the waterproofing that holds the water; tiles and grout are a protective and decorative layer above it. For roofs and tanks elsewhere on the villa, see roof waterproofing in Hafr Al-Batin.
Pool tiling in Hafr Al-Batin with a full bed of adhesive
Pool tiling labour in Hafr Al-Batin is priced from SAR 92 per square metre, and glass mosaic from SAR 110 per square metre supplied, yet the real difference from tiling a room floor lies in how the tile is stuck down. Under water it is not acceptable to fix tiles on dabs of adhesive or on a partial bed. Every tile needs a complete bed of adhesive beneath it with no voids, because a void fills with water under pressure, the tile weakens and eventually lets go, and the hollow becomes a place for algae to grow.
How do we make sure the adhesive bed is complete?
We comb adhesive onto the floor or wall with a notched trowel and also butter the back of each large tile, then set the tile, slide it slightly and tap it with a rubber mallet so the adhesive grips both faces. Every so often we lift a freshly laid tile to confirm its back is fully covered. We use a modified cementitious adhesive rated for immersion and tiles with low water absorption, ideally under 0.5%.
- ✓Notched trowel: the notch size matches the tile size, and larger tiles need larger notches.
- ✓Back-buttering: adhesive on the surface and on the back of large tiles fills any warp in the tile.
- ✓Lift checks: a tile is lifted now and then to confirm full coverage.
- ✓Tap test: a hollow tile rings when tapped, so it is lifted and re-bedded before the adhesive sets.
Grout and movement joints
Tiles are left for at least three days before grouting, and we use epoxy grout where chlorine and moving water are heaviest, such as under the waterfall and around the return inlets. Movement joints are planned where walls meet the floor, because the shell moves slightly with temperature and with filling. The coping is slip-resistant, and laying the surrounding deck to proper falls costs from SAR 37 a square metre in labour. For other tiling around the villa, see tile installer in Hafr Al-Batin.
When do we fill the pool?
We wait roughly three weeks after the last tile, then let the level climb slowly, no faster than three-quarters of a metre or so per day, so the adhesive takes up the load bit by bit.
Stainless steel pool ladders and handrails in Hafr Al-Batin
A stainless steel pool ladder starts from SAR 460 supplied and installed, fixed into anchor sockets cast into the coping stone or the concrete edge. The important part is timing: the sockets go in before the edge is cast or before the coping is laid, not afterwards by breaking through finished tiles, so the waterproofing beneath them stays intact.
Where does the ladder go, and what spacings apply?
We usually place the ladder at the deep end, where feet cannot reach the floor, and put built steps or a handrail at the shallow end. International guidance for residential pools puts ladder tread spacing between about 18 and 30 cm, handrail height between about 76 and 97 cm, and built step risers no higher than about 19 cm with treads at least about 25 cm deep. We also leave enough clearance around the ladder to climb out without scraping the wall.
- ✓Stainless grade: a grade suited to treated water, cleaned of chlorine and scale marks from time to time.
- ✓Sockets: cast in and sealed, with waterproofing dressed around them before tiling.
- ✓Earthing: ladders and rails are metal beside water, so they are bonded to the equipotential and earthing system.
- ✓Treads: a slip-resistant surface on every step.
A wall waterfall spilling into your pool in Hafr Al-Batin
In Hafr Al-Batin, a wall waterfall above the pool costs from SAR 3,700 when it is around a metre square, from SAR 6,450 at about 2 × 1.5 m, and from SAR 11,000 for a broad face of three by two metres or more. A contemporary corner design begins at SAR 5,500, and submerged lights to show it off at night add from SAR 460. A waterfall is a water circuit: a pump draws water and lifts it through pipes hidden inside the wall to the outlet, where it either slides over stone or falls as a sheet onto the pool surface.
How do we protect the wall behind the waterfall?
A wall that has water running down it must be waterproofed before it is clad, or water will soak into the blockwork and from there into the boundary wall or the villa. We either build a separate waterfall wall or waterproof the boundary wall with an immersion-grade coating, run the pipes inside it, clad it in stone with adhesive made for wet areas and seal the joints. We also leave an access hatch so the fittings can be reached without breaking stone. Rendering the wall before waterproofing is covered in plastering contractor in Hafr Al-Batin.
| Water feature for your garden | Entry price |
|---|---|
| Waterfall on the garden wall, roughly one metre wide and high | SAR 3,700 each |
| Waterfall on the garden wall, about 2 × 1.5 m | SAR 6,450 each |
| Broad waterfall face, three by two metres and up | SAR 11,000 each |
| Contemporary corner waterfall, mid-sized | SAR 5,500 each |
| Natural-stone cascade at ground level between planters | SAR 7,400 each |
| Garden fountain, small or mid-sized | SAR 3,200 each |
| Underwater lamp kit to light the feature at night | SAR 460 per set |
Stone-clad built planters around the pool
Built planters around a pool in Hafr Al-Batin give the garden year-round green, but they hold wet soil and irrigation water right beside pool water. So we build them separately from the pool wall, waterproof them inside, and send their drainage away from the pool, never into it, so irrigation water carrying soil and fertiliser does not reach the water you swim in.
- 1Base and walls
A concrete base, then block or concrete walls to the agreed height, then render. - 2Drain outlets first
Weep holes and outlets pointed away from the pool, set before waterproofing. - 3Internal waterproofing
Covering the floor and walls up to above the soil line. - 4Drainage layer
Gravel and geotextile fabric so soil does not block the outlets. - 5Root barrier
Protecting the waterproofing from roots before the soil goes in. - 6Stone cladding
Stone fixed with exterior-grade adhesive and a capping that stops water getting behind it.
We quote planters on site, since the cost follows their run, their height and the stone you pick. We do not plant; we hand the planter over ready for soil and plants.
Pool plumbing, power and equipment in Hafr Al-Batin
All pool plumbing in Hafr Al-Batin is set before the shell is cast: a pair of floor outlets for each pump, spaced not less than roughly ninety centimetres apart (or another arrangement that stops a swimmer being held by suction), wall jets for returning water, skimmer bodies, a dedicated line for the waterfall pump and pressure pipes back to the equipment room. Each run is pressurised and checked while it is still exposed. For general plumbing in the villa, see plumber in Hafr Al-Batin.
The submerged lamps in pool and waterfall are low-voltage (12 V) units fed from a transformer mounted well away from the water; ladders, rails and other metal close by are bonded into the earthing, and a 30 mA earth-leakage breaker guards the whole circuit. Pump, filter, salt or other sanitising, and any heating or cooling unit are left to the specialist to select, and we price them once selected. Wiring in the rest of the garden is covered by our electrician in Hafr Al-Batin page.
Garden pool safety
A fence around the pool is the most important protection for children. International advice puts it at 1.2 metres high or more, with no opening wide enough for a ten-centimetre ball to slip through, and a gate that swings shut and latches by itself. In a garden, watch for planters and benches placed against the fence, because a child can use them as a step to climb over, so we keep them clear of it. Floor drain covers are approved anti-entrapment types, and the deck around the pool and beneath the waterfall is slip-resistant.
Mistakes we keep seeing in garden pools
A planter built hard against the pool wall without waterproofing, so its damp seeps into the shell. A waterfall on an unwaterproofed boundary wall, so salts and flaking appear on its outer face. Ladder sockets drilled after tiling, breaking the waterproofing beneath them. Tiles fixed on dabs of adhesive that ring when tapped and then come loose. A deck with no falls that sends irrigation and washing water back into the pool. Each of these is prevented by a small decision at the right moment, and each costs many times more to put right later.
Swimming pool construction prices in Hafr Al-Batin
Being in Hafr Al-Batin does not change our entry prices; they match what we charge in Dammam, and only the trips are added, once the site has been seen. Each pool figure below includes digging in normal ground, the reinforced shell, the inner waterproofing, pool ceramics, pipework that has passed its pressure test, and a plant room ready for the machinery.
| For your garden in Hafr Al-Batin | Charged per | Lowest price |
|---|---|---|
| Compact garden pool of 2.5 × 4.5 m or so, about a metre deep | whole pool | SAR 12,900 |
| Typical garden pool 3 by 6 m on skimmers, sloping from 0.75 down to 1.4 m | whole pool | SAR 19,400 |
| Lap-friendly pool near 4 by 9 m on skimmers, sloping from 0.9 down to 1.8 m | whole pool | SAR 29,500 |
| Generous pool near 5.5 by 10.5 m on skimmers, sloping from one to two metres | whole pool | SAR 38,800 |
| Brim-full pool with perimeter channel and balance tank | whole pool | SAR 60,000 |
| Two coats of flexible cement-based membrane inside | square metre | SAR 74 |
| Laying pool tiles on a solid adhesive bed (labour) | square metre | SAR 92 |
| Glass mosaic for the pool (material) | square metre | SAR 110 |
| Laying the surrounding deck to falls (labour) | square metre | SAR 37 |
| Stainless ladder with its sockets, fitted | each ladder | SAR 460 |
| Check-up visit to a pool already in the garden | each visit | SAR 140 |
| Stone planters around the pool | run and height | priced on site |
| Crew trips to Hafr Al-Batin | number of stages | priced on site |
| Machinery, lamps, safety fence, any soil swap | your selection | priced on site |
Everything above is an estimate until inspection and agreement; pool size, depth and system, the stone and finish level, the ground itself and whether a digger can reach the garden all move the figure. Other services are listed on our price estimates page.
Worked example: a 4×9 m pool with a wall waterfall in a villa garden
An illustrative example for a villa garden with a pool of about 4×9 m on a skimmer system, a medium wall waterfall of about 2×1.5 m on the back wall with underwater lighting, and a stainless ladder at the deep end:
| Item | Calculation | Cost from |
|---|---|---|
| Garden pool, 4 by 9 m | from the pool table | SAR 29,500 |
| Back-wall waterfall, near 2 by 1.5 m | from the waterfall table | SAR 6,450 |
| Underwater waterfall lighting | one set | SAR 460 |
| Stainless ladder | 1 × 460 | SAR 460 |
| Total before planters, equipment and travel | 29,500 + 6,450 + 460 + 460 | SAR 36,870 |
Items set at inspection are added to that: the stone planters by length, the equipment through the supplier, the fence, travel and any soil replacement.
What changes the cost of a garden pool?
- ✓Stone type: natural stone on coping, planters and the waterfall costs more than tiles.
- ✓Waterfall height and width: they set the pump size and the quantity of stone and waterproofing.
- ✓Depth: every extra bit of depth adds excavation, concrete and tiles.
- ✓Interior finish: glass mosaic costs more than pool ceramic tiles.
- ✓Access: a garden a machine cannot enter needs hand digging and longer haulage.
Pool renovation in Hafr Al-Batin
Pool renovation in Hafr Al-Batin starts with an inspection visit from SAR 140. What we see most in older pools is tiles that came loose because they were fixed on a partial bed, worn grout, or ladders whose sockets have corroded. Usually the cure is to take the old tiles off (from SAR 14 a square metre), lay fresh waterproofing (from SAR 74), re-tile on solid adhesive (labour from SAR 92) and replace corroded sockets and ladders. Through-cracks in the shell need an engineering report, and repair methods are covered in crack repair in Hafr Al-Batin. For wider renovation work, see renovation contractor in Hafr Al-Batin.
Does a pool need a permit in Hafr Al-Batin?
Before we put a spade in the ground, we ask a licensed engineering office to confirm whether your pool needs approval. With a villa that is already built, it normally goes through Balady as a request to «add and modify building components», which needs a building permit still in force; Balady states one to ten days for this service, with fees from its own calculator. On a villa still being designed, the engineer simply shows the pool in the original permit set.
Looking after the pool, waterfall and planters
- ✓Water: each day the pool is used, check that pH reads 7.0–7.8 and free chlorine is 1 ppm or above.
- ✓Dust: cover the pool on dusty days, then empty the skimmer baskets and backwash the filter.
- ✓Waterfall: check the water level and pump strainer weekly and descale the outlets monthly.
- ✓Planters: water moderately and check the drain outlets so they do not block.
- ✓Ladders: clean the stainless steel and tighten the bolts from time to time.
How to order a pool in Hafr Al-Batin
To get a first figure quickly, message 0547879578 on WhatsApp and include:
- ✓Garden photos: from several angles, including the wall you want the waterfall on.
- ✓Dimensions: how long and wide the garden is, and roughly how big a pool you are picturing.
- ✓Planters: where you want them and whether you prefer stone or tile cladding.
- ✓What is underground: the septic tank, water tank and any known pipes.
- ✓District: the district name or a map pin.
- 1First figures
We work them out from your photos and our entry prices, flagging what still needs a site visit. - 2Inspection
Measuring the garden, checking the soil and the wall, and fixing the levels. - 3Agreement and drawing
Items, stages and number of trips, with the permit through an engineering office. - 4Construction
The shell, then the wall and planters, then waterproofing, tiling and cladding, then the equipment. - 5Handover
A filled pool, a running waterfall and planters ready for planting, with care instructions.
Why Aemar Al-Maryam for your garden pool in Hafr Al-Batin?
Because we build the garden as one project: the pool, waterfall and planters on levels calculated together, waterproofing that keeps irrigation water apart from pool water, tiles on a full adhesive bed that do not ring or come loose, and ladders fixed in sockets cast in before the finishes. The bare shell is water-tested before a single tile goes on, each pipe is pressurised before it disappears, and our entry prices are public. Browse finished projects, read the pools and waterfalls service overview, or go deeper with swimming pool construction in Dammam.
Hafr Al-Batin districts where we build pools
Our coverage of the city is summarised on the Hafr Al-Batin area page. Sister articles in this series deal with rest-house pools in swimming pool construction in Al-Ahsa and beach-villa pools in swimming pool construction in Khafji.
Photograph your garden and its back wall
Share a few pictures and rough sizes; we reply with a suggested pool, a spot for the waterfall and planters and a ballpark cost, then book our trip to Hafr Al-Batin.
